Abailable In Stock
- 1/2.7" 2.4MP PS CMOS Image Sensor
- Max 25/30fps@2.4MP
- DWDR, Day/Night(ICR), 2D-DNR, AWB, AGC, BLC, HLC
- 3.6mm fixed lens (2.8mm optional)
- IR Range of 20 Mtrs., IP67
- OSD Menu, control over coaxial cable, 2D-DNR
- HD, SD and Two other Analog format Output switchable
- Image Sensor: 1/2.7" PS CMOS
- Minimum Illumination: 0.02Lux/F1.85, 30IRE, 0Lux IR on
- Effective Pixels: 2.4MP
- Angle of View: 87.5° (103°)
- Shutter SpeedPAL: 1/25~1/100000s NTSC: 1/30~1/100000s
- White Balance: Auto / Manual
- Lens: 3.6mm (2.8mm Optional)
- Gain Control (AGC): Auto / Manual
- S/N Ratio: More than 65dB
- Back Light Comp.: BLC / HLC / DWDR
- Video Streaming: 25/30fps@2.4MP, 25/30/50/60fps@720P
- Video Output1-channel BNC high definition video output / CVBS video output (Can switch)
- ICR: Auto (ICR) / Manual
- OSD: Multi-language
- IRIR Range of 20 Mtr.
- Operating Temperature:-40°C~+60°C / Less than 95%RH
- Power Source: 12V DC ±30%
- Power Consumption:Max 3.3W (12V DC, IR on)
- Weatherproof Standard:IP67
- Dimension:Φ97mm×79.3mm(Φ3.8"×3.1")
- Weight:0.17kg
- Image Sensor1/2.7" PS CMOS
- Minimum Illumination0.02Lux/F1.85, 30IRE, 0Lux IR on
- Effective Pixels2.4MP
- Angle of ViewH: 87.5° (103°)
- Shutter SpeedPAL: 1/25~1/100000s NTSC: 1/30~1/100000s
- White BalanceAuto / Manual
- Lens3.6mm (2.8mm Optional)
- Gain Control (AGC)Auto / Manual
- S/N RatioMore than 65dB
- Back Light Comp.BLC / HLC / DWDR
- Video Streaming25/30fps@2.4MP, 25/30/50/60fps@720P
- Video Output1-channel BNC high definition video output / CVBS video output (Can switch)
- ICRAuto (ICR) / Manual
- OSDMulti-language
- IRIR Range of 20 Mtr.
- Operating Temperature-40°C~+60°C / Less than 95%RH
- Power Source12V DC ±30%
- Power ConsumptionMax 3.3W (12V DC, IR on)
- Weatherproof StandardIP67
- DimensionΦ97mm×79.3mm(Φ3.8"×3.1")
- Weight0.17kg
