| Rear fitting | 1 x, cable diameter 4.0 to 7.0 mm (0.16 to 0.28 in) |
| Rear fittings | 2 x, cable diameter 6.5 to 10.5 mm (0.26 to 0.42 in) |
| Bottom feeds | 2 x, cable diameter 4.0 to 7.0 mm (0.16 to 0.28 in) |
| Window | 3 mm (0.12 in) glass |
| Locking clasps | Tamper-resistant screws provided |
| Camera power ratings | 24/120/230 VAC, 50/60 Hz, 6.3 A |
| Camera mounting | Removable camera/lens tray, mounted with two screws |
| Max camera + lens size (H x W x L) | 81 x 89 x 317 mm (3.19 x 3.50 x 12.48 in) |
| Construction | Aluminum casing, neoprene gaskets, all stainless steel hardware |
| Dimensions | See drawings |
| Weight | 2.3 kg (5.1 lb) |
| Mounting | 2 x pair of tapped holes |
| thread | 1/4-20 |
| inner pair | 50.8 mm (2.0 in) center spread |
